IEC60335-2-3 Electrical Appliance Tester Cordless Iron Insert And Withdraw Endurance Tester 10 Times / Min
IEC60335-2-3
22.105 The connection contacts of cordless irons shall be constructed so that any electrical or mechanical failure occurring in normal use will not give rise to a hazard.
Compliance is checked by the following test.
The two live pins of the iron are connected together and an external resistive load is connected in series with the supply. The external load is such that the current is 1,1 times rated current when the iron is supplied at rated voltage.
The iron is placed on its stand and withdrawn 50 000 times, at a rate of 10 times per minute.
The test is continued for a further 50 000 times without current flowing.
After the test the iron shall be fit for further use and compliance with 8.1, 16.3, 27.5 and Clause 29, shall not be impaired.
Standard of Electrical Appliance Tester: IEC 60335-2-14 Clause 22.103, IEC60335-2-3 Clause 22.105, IEC60335 -2- 15 clause 22.103 and etc.
Application of Electrical Appliance Tester: Cordless electric kettles, cordless irons, cordless blenders, the contacts shall be constructed so that any electrical or mechanical failure that occurs during normal use shall not be dangerous and shall be verified by a plug-in test.
Test sample of Electrical Appliance Tester: Cordless electric kettles, cordless irons, cordless blenders
Feature of Electrical Appliance Tester: Make the two contacts of cordless electric kettles, cordless irons, cordless blenders to be Short-circuit, and supply 1.1 times of rated voltage to cordless electric kettle/ iron/ blender, then process the endurance test that the test sample’s body insert into and plug from the base at the speed of 10 times/min. And then process a certain times of insert & plug endurance test without load voltage. The test device can be connected to external load or has built-in load (optional), the test cycles can be preset (maximum 999999),the test system can record the test cycles and conduction cycles automatically during test, when the preset test cycles have been completed, the test device will stop testing automatically.
Parameters:
| Parameters / Model | HJ0613A |
| Input Power | AC220V 50HZ |
| Control | PLC control, touch screen operation |
| Station | Single station |
| Drive Method | motor-driven |
| Test Sample | Cordless water kettle/iron/blender |
| Insert & Plug Stroke | 0-100mm,can be preset on touch screen |
| Insert & Plug Speed | 0-30 times/min, can be preset on touch screen |
| Test Cycles | 0-999999,can be preset on touch screen |
| Conduction Cycles | 0-999999, can be displayed |
| Mechanical action | insert & plug action and kettle switch open and close movement |
| Load | Built-in 0-250V,0-15A |
| Sample judgment | Judge conduction according to the current |
| Dimensions and Weight | 1000×500×1200mm,200kg |
Picture for reference:
